Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, Magnetic mount |
| Protection Level of Chassis | IP66 |
RF Interface |
| Radio Standard | 802.15.4e |
Supported Protocols |
| Industrial Protocols | MQTT client |
Analog Input |
| Total channels of analog input | 3 |
| Number of Bits | 12 Bit |
| Voltage range | 0...5 V |
| Current range | 0...20 mA, 4...20 mA |
Digital Output |
| Total channels of digital output | 1 |
| Type | Open collector |
| Output voltage | 0~30 V |
| Max. load current | 100 mA |
Connectors |
| Connectors | M12 |
System Power Input |
| Input Voltage DC | 3.6...3.6 V |
Dimensions and weight |
| Width | 95.3 mm |
| Depth | 116 mm |
| Height | 65.2 mm |
Operating Conditions |
| Operating Temperature | -40...80 °C |
Standards and Certifications |
| EMI | EN 55022, FCC Part 15, CISPR 22 Class |
| EMS | IEC 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-4 |
| Oil And Gas | UL/cUL Class I Division 2 Groups A/B/C/D |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
