System Architecture | |
| Form Factor | 3.5" |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Processor Installed | Intel Core i5-1145G7E |
| Max CPU frequency | 4.1 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| M.2 | 1 |
Connectors | |
| Connectors | HDMI, 2xRJ45, 4xUSB, 4-pin DC input |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
