System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Alder Lake, Raptor Lake |
| Socket | LGA1700 |
Chipset | |
| Chipset | Intel Q670E |
Memory | |
| Socket Type | 2xSODIMM 262-pin |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
| Interfaces | LVDS, 3xHDMI, eDP |
Ethernet | |
| Controller Type | Intel i219-LM, Intel i226V |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 2,5 Gbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALS888S |
Extension Slots | |
| Total | 3 |
| M.2 | 3 |
Connectors | |
| Connectors | 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, DC Input, 3xHDMI |
Software | |
| Operating System Compatibility | Linux OS, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
