Ethernet |
| Total Ethernet | 12 |
| 10 Gbit SFP+ Ports | 12 |
Switch Properties |
| Managed | Yes |
| Switch Level | Layer 3 |
| MAC Table Size | 32000 |
| Jumbo Frame Size | 12 kB |
Supported Protocols |
| Industrial Protocols | Modbus TCP |
| Protocol Layer 3 | Static Routing, RIP V1/V2, OSPF |
| Managment Protocols | ARP, Proxy ARP, IGMP Snooping v1/v2/v3, IGMP Querier, GVRP, CoS, LACP, DHCP Option 66/67/82, Telnet, SNMPv1/v2c/v3, FTP, TFTP, NTP |
| Security Protocols | TACACS+, RADIUS, SSH, SSH2 |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X), IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3ab for 1000BaseT(X), IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3x for Flow Control, IEEE 802.3ad for Port Trunk with LACP, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1Q for VLAN Tagging, IEEE 802.1P for Class of Service, IEEE 802.1X for Authentication |
Connectors |
| Connectors | DB9 |
System Power Input |
| Input Voltage AC | 100...240 V |
Construction |
| Protection Level of Chassis | IP30 |
| Height | 1 U |
Dimensions and weight |
| Width | 330 mm |
| Depth | 230 mm |
| Height | 43.6 mm |
Operating Conditions |
| Operating Temperature | 0...50 °C |
| Humidity | 5-95% |
Standards and Certifications |
| Certifications | CE, FCC Class A |
