Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Memory | |
| Default on Board Memory | 4 GB |
Installed drive | |
| Flash Memory Capacity | 64 MB |
| EEPROM Memory Capacity | 16 kB |
| MRAM Memory Capacity | 128 kB |
| 1st Storage Capacity | 32 GB |
Drive interfaces | |
| CompactFlash Slots | 1 |
Expansion Module | |
| Quantity of Slots | 1 |
| Supported Module | I-9K series, I-97K series |
Software | |
| Operating System Installed | Windows IoT Enterprise 10 |
| Programming Method | C/C++ |
| Development Software | Visual Studio .NET |
Ethernet | |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 1 |
| RS-485 | 1 |
| RS-232/485 | 2 |
| USB Total | 4 |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Connectors | |
| Connectors | spring clamp terminal block |
Graphic | |
| Interfaces | HDMI, VGA |
Dimensions and weight | |
| Width | 239 mm |
| Depth | 164 mm |
| Height | 133 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
| Power Supply Reserve input Voltage DC | 10...30 V |
| Redundant power input | Yes |
Operating Conditions | |
| Operating Temperature | -25...60 °C |
