Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel, Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Celeron J3455 |
| Max CPU frequency | 2.3 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | DB9, HDMI, 2xRJ45 Ethernet, 2xUSB, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 19...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 90 W |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 520.6 mm |
| Height | 315.6 mm |
| Depth | 54 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
| Vibration | 2Grms @ sine. 5~500Hz. 1hr/axis; 2.2Grms @ random condition. 5~500Hz. 0.5hr/axis (non-operating) |
| Shock | 50g peak acceleration (11 msec. duration) |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
