Construction | |
| Construction Chassis | Aluminium Chassis, Open Frame |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD |
| Diagonal | 23.8 " |
| Maximum resolution | 1980x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1000~1 |
| Input Interface | HDMI |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Processor Installed | Intel Core i3-1115G4E, Intel Core i5-1145G7E |
| Socket | FCBGA 1449 |
| CPU Support Type | Core i3, Core i5 |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xDDR4 SODIMM 260-pin |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics, Intel Iris Xe Graphics |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2230 E |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | DB9, HDMI, 2xRJ45 Ethernet, 4xUSB, Line Out, DC Input, Display Port |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 96 W |
| AC input voltage | 100-220 V |
Software | |
| Operating System Compatibility | Windows 10, Linux OS |
Dimensions and weight | |
| Width | 557 mm |
| Height | 336.7 mm |
| Depth | 55 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Humidity | 10-90% |
| Vibration | IEC 68 2-64 - 2G @ sine. 5~500Hz. 1hr/axis - 2.2Grms @ random condition. 5~500Hz. 0.5hr/axis (non-operating) |
| Shock | IEC 68 2-27 - 20g peak acceleration (11 msec. duration) |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
