Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in |
Analog Output | |
| Channels of analog input | 4 |
| DAC Bit Rate | 12 Bit |
| Voltage range | 0...5 V, 0...10 V, +/-5 V, +/-10 V |
| Current range | 0...20 mA, 4...20 mA |
Digital Input | |
| Total channels of digital input | 4 |
| Type | Wet contact |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 3.5~50 V |
| Sink/Source | Wet: Sink/Source |
| Counter capacity | 32 Bit |
| Max frequency | 0.5 kHz |
| Counter | 500Hz, 32 bit |
Digital Output | |
| Total channels of digital output | 4 |
| Type | Electromagnitic relay |
| Relay (Form A) | 4 |
| Contact rating of relay (Form A) | 6A@240V AC, 6A@35V DC |
System Power Input | |
| Input Voltage DC | 5...5 V |
Dimensions and weight | |
| Width | 59 mm |
| Depth | 13 mm |
| Height | 82 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2 |
