ZT-2043-IOG

Name: ZT-2043-IOG
Brand: ICP DAS
SKU: 56417000
Availability: InStock

ICP DAS

Ціна за запитом

ZigBee I/O Group (Pair-connection) Module with the 14-channel Isolated Digital Output (ZigBee Coordinator and ZigBee Router)(RoHS)

Специфікація

Specification

Construction
Construction Chassis	Plastic Chassis
Mounting Configuration	Wall, DIN-Rail mount
RF Interface
Radio Standard	ZigBee (Host, Coordinator)
Supported Protocols
Industrial Protocols	Modbus RTU slave, DCON slave
Digital Output
Total channels of digital output	14
Type	Open collector
Output voltage	5~50 V
Max. load current	700 mA
Connectors
Connectors	Screw Terminal
Additional Functions
Watchdog timer type	Hardware, Software
System Power Input
Input Voltage DC	10...30 V
Dimensions and weight
Width	33 mm
Depth	87 mm
Height	110 mm
Operating Conditions
Operating Temperature	-25...75 °C
Standards and Certifications
Certifications	CE, FCC
EMS	IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5

Документація
