Specification
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | 19" Rackmount, Wall, DIN-Rail mount |
Expansion Module | |
| Quantity of Slots | 9 |
| Supported Module | 85M series, 86M series |
Dimensions and weight | |
| Width | 325 mm |
| Depth | 100 mm |
| Height | 134 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| EMI | EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Explosion safety | ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| Freefall | IEC 60068-2-32 |
| Rolling Stock | EN 50121-4, EN 50155, EN 50121-3-2 |
| Safety | UL 508 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
