Construction |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in, Desktop, Wall, Pole Mount |
| Type | Fanless |
CPU |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Atom x5-E3930 |
| Socket | FCBGA1296 |
| Max CPU frequency | 1.8 GHz |
Memory |
| Form-factor | DDR3L |
| Socket Type | Soldered |
| Default on Board Memory | 4 GB |
| Assembly | Fixed on Board |
Graphic |
| Graphic Controller | Integrated in CPU, Intel HD Graphics 500 |
| Interfaces | HDMI |
Ethernet |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces |
| SD Slots | 1 |
Installed drive |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 16 GB |
Extension Slots |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | Yes, 1 |
LED / Controls |
| LED | 1xHDD LED, Power LED, Battеry Status, TX LED, RX LED, LAN LED |
| Controls | On/Off |
Additional Functions |
| Watchdog timer type | Software |
Connectors |
| Internal Ports | USB 2.0, 10-pin RS-232, 10-pin GPIO |
| Connectors | 4xUSB, HDMI, SD card slot, 2xRJ45 Ethernet, 2xDB9 |
System Power Input |
| Input Voltage DC | 19.2...28.8 V |
| Power Consumption | 60 W |
Software |
| Operating System Compatibility | Windows 10 |
Dimensions and weight |
| Width | 78.2 mm |
| Height | 120 mm |
| Depth | 100 mm |
Operating Conditions |
| Operating Temperature | -20...70 °C |
| Humidity | 10-95% |
| Vibration | 2G |
| Shock | 50G |
Standards and Certifications |
| Certifications | CE, FCC Class A, EN61000-6-2, EN61000-6-4 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-64 |
