Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | 1xRJ-45 |
Interfaces |
| COM Total | 8 |
| RS-232 | 8 |
Digital Output |
| Total channels of digital output | 1 |
| Type | Signal Relay |
Supported Protocols |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, BootP, HTTP, Telnet, TCP, UDP, DHCP, DNS, ARP, ICMP |
| Security Protocols | DES, 3DES, AES, SSH, SSL |
Expansion Module |
| Quantity of Slots | 1 |
| Supported Module | NM series |
LED / Controls |
| LED | Module Fail, Power LED, READY LED, COM-ports LED, LNK/ACT LED |
| Setup of Operation Mode | Telnet, Console Port, By Switches, Buttons for Setting up and Displaying Status, Web-interface |
Connectors |
| Connectors | SD card slot |
System Power Input |
| Input Voltage AC | 100...240 V |
Operating Conditions |
| Operating Temperature | 0...55 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
Dimensions and weight |
| Width | 440 mm |
| Depth | 195 mm |
| Height | 44 mm |
Standards and Certifications |
| Certifications | CE, WEEE, FCC |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 55024 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-6 |
